High Impact Safety Guards

High Impact Safety Guards are a specialized safety solution designed to protect both people and infrastructure in industrial environments. Thanks to its elevated construction, it provides protection at a raised level, making it ideal for specific applications.

Main Advantages:
  • Dual Protection – Simultaneously protects pedestrians and workers from vehicle collisions, as well as buildings and infrastructure from damage
  • Elevated Level of Protection – High-leg design allows installation at an elevated position for better visibility and effectiveness
  • Deformation zone – due to their design and durability, they take up minimal space
  • Hygienic Solution – Impact panels are hygienic, indestructible, washable, and fully recyclable
  • Versatile Use – Suitable for demarcating work areas, protecting production equipment and energy sources
  • Durable Construction – Extremely resistant to mechanical damage and repeated impacts
  • Easy Maintenance – Washable surface enables simple maintenance and cleaning

This product is ideal for areas where personal and property protection needs to be combined at a level above standard floor-mounted installations.

High Impact Safety Guards protect
High Impact Safety Guards
High Impact Safety Guards
High Impact Safety Guards
High Impact Safety Guards
High Impact Safety Guards

Technical Specs

Download Technical Specs in PDF

Diameter
D - mm
Height
H - mm
Length
L - mm
Resistance
Joules
Anchoring Pullout
kN
Total Floor Space
mm
IP Grade Flame Extinguishing Rate
70 225 500-1000-1500-2000 9 369 190 94 59 UL94: HB
70 270 500-1000-1500-2000 9 369 190 94 59 UL94: HB
100 250 500-1000-1500-2000 19 360 190 140 59 UL94: HB
100 300 500-1000-1500-2000 19 360 190 140 59 UL94: HB
120 295 500-1000-1500-2000 33 950 190 183 59 UL94: HB
120 365 500-1000-1500-2000 33 950 190 183 59 UL94: HB


 Customized solution and colours upon request

Impact Energy Calculator

Weight
Speed
Angle

(please fill in the details for calculation)

Impact energy result - Joules

0
10 000
12 500
20 000
25 000
30 000
37 500
40 000
50 000
..... Joules
worker

Precisely What You Need

Call our Safety Consultant and receive a free, no-commitment Safety Assessment tailored to your needs.

Tel.: +39 347 46 74 056 / E-mail: info@bambarrier.com

Contact form
qr code for mobile number

Technology

FLEXAFE™

Cutting-Edge Polymer material, designed specifically to absorb high-level impacts in a very small space. It is food-safe, doesn't break or flake, and 100% recyclable.

FOOD SAFE

Resistance to Ultra-Violate Light DIN-EN-ISO 8777-8 Blue Scale

100% recyclable

Temperature Range -40° to +50°

Why is it beneficial to use FLEXAFE?

ROOTLOCK®

World‘s most advanced and safe Anchorage System. It helps the floor to absorb violent and repeat vehicles impacts without damaging the floor.

Cutting-edge Anchorage System Design

Anti-Shrinkage Cement

What makes ROOTLOCK® special?

Applications

Good Protection

Bad Protection

Compliant Crash Testing


We test our products in compliance with the industry‘s World-class standards: PAS13:2017 and UNI 11886.

  • We measure barriers resistance in „Joules“ according to the following formula:
    Kinetic Energy = 1/2*m*v² | M= Mass (Kg) and V = Velocity (Km/h)
  • We make sure test only on real floor: armed concrete; we don‘t test on metal platforms.
  • We make sure vehicle impact takes place at the worst-scenario angle: 90°.

Finally, Bambarrier product is certified compliant when:

  • It stops the crashing vehicle safely without breaking itself and without breaking the floor.
  • It can be hit repeatedly without getting loose and without breaking the floor.
  • When after an impact, it occupies a very small space on the floor.
